Webhook Retry Policy: Exponential Backoff & Schema

/ The policy

What is a good webhook retry policy?

A retry policy is the set of rules that decide what happens after a delivery fails. A sane default has four moving parts: retry on 5xx, 429, and network or timeout errors; back off exponentially with a ceiling so you stop hammering a struggling endpoint; cap the total at around five attempts spread over a few hours; then move the delivery to a dead-letter state for manual replay instead of retrying forever.

Everything else is tuning. The numbers below are a starting point, not a law — a payment provider and an internal analytics sink deserve different ceilings — but the shape is the same across almost every production webhook system, from Stripe's webhook delivery down to a single WordPress site.

/ Backoff

Why exponential backoff instead of fixed intervals?

Because the failure is usually the receiver being briefly overloaded or down. A fixed-interval retry hammers a struggling endpoint at a constant rate and can keep it down; exponential backoff gives the receiver geometrically more time to recover on each attempt while still retrying quickly for a one-second blip.

Add jitter — a small random offset on each delay — so a fleet of senders that all failed at the same moment does not re-fire in lockstep and create a thundering herd at every interval boundary. Even on a single site, jitter spreads retries off the exact minute mark and away from the rest of your cron load.

/ The schedule

What backoff schedule should you use?

Double the delay each attempt from a small base, cap it, and stop after a fixed count. A widely used shape is base 30 seconds, factor 2, ceiling 1 hour: roughly 30s, 1m, 2m, 4m, 8m, then any further attempts pinned at the cap. The formula is delay = min(cap, base * 2 ^ (attempt - 1)), plus a jitter term.

This is exactly the schedule the Webhook Actions plugin ships: 5xx and 429 responses retry with delays of about 30s, 60s, 120s, 240s, and 480s, capped at one hour, with a default of five attempts that you can override with the fswa_max_attempts filter.

PHP — exponential backoff with jitter

function next_retry_delay( int $attempt ): int {
    $base = 30;     // seconds
    $cap  = 3600;   // 1 hour ceiling

    $delay = min( $cap, $base * ( 2 ** ( $attempt - 1 ) ) );

    // add up to 20% jitter so retries do not synchronize
    return $delay + random_int( 0, (int) ( $delay * 0.2 ) );
}

/ The schema

What database schema tracks retries?

Two tables. A deliveries row represents one logical webhook send and carries the state machine; an attempts row records each physical HTTP try so you keep the full request and response history. Splitting them keeps the hot path (find due deliveries) on a small, well-indexed table while the verbose request and response bodies live separately.

The columns that matter on deliveries: an event_id as the idempotency key, the endpoint and payload, a status enum (queued, sending, delivered, failed, dead), an attempt_count, and a next_attempt timestamp the runner queries against. Index on (status, next_attempt) so "what is due now" stays fast as the table grows.

SQL — deliveries table (the hot path)

CREATE TABLE wp_webhook_deliveries (
  id            BIGINT UNSIGNED AUTO_INCREMENT PRIMARY KEY,
  event_id      CHAR(36)     NOT NULL,            -- idempotency key
  endpoint_url  VARCHAR(512) NOT NULL,
  payload       LONGTEXT     NOT NULL,
  status        VARCHAR(20)  NOT NULL DEFAULT 'queued',
  attempt_count SMALLINT     NOT NULL DEFAULT 0,
  next_attempt  DATETIME     NULL,
  created_at    DATETIME     NOT NULL,
  UNIQUE KEY uq_event (event_id),
  KEY due (status, next_attempt)
);

/ What to retry

Which responses should trigger a retry?

Retry 5xx and 429; never retry 4xx (except 429) or 3xx. A 5xx means the receiver broke on a request that may be fine next time. A 429 means slow down — back off and try again. A 4xx like 400 or 422 means the payload itself is wrong, so retrying just fails again more slowly; mark it permanently failed and surface it. A 3xx redirect is a configuration problem, not a transient one.

Treat network-level failures — DNS, connection refused, timeouts — like 5xx: retry them. They are the most common transient failure of all, and a request that timed out may well have one foot in the door, which is exactly why the next section matters.

/ When to stop

How do you stop retrying — dead-letter and idempotency?

Cap the attempts. When a delivery exhausts its budget, set its status to dead and surface it for manual replay rather than retrying forever; an endpoint that has failed five times over an hour is down, not flaky. A dead-letter state turns an invisible silent failure into a queue someone can actually action.

Pair retries with an idempotency key — the event_id column above — sent as a header so the receiver can dedupe. Any retry policy is at-least-once delivery by definition: a request that timed out may have succeeded on the receiver before your timeout fired, so a retry delivers it twice. The key lets the receiver collapse those duplicates, the same pattern Stripe documents for its own webhooks. For a WordPress-specific build of this whole loop, see the retry and replay system walkthrough.

Retrying a 400 is just a slower way to fail. Backoff is for problems that time can fix. — Retry design, in one line
