Webhook Retry Policy: Exponential Backoff and the Delivery Schema

/ The policy

What is a good webhook retry policy?

A retry policy is the set of rules that decide what happens after a delivery fails. A sane default has four moving parts: retry on 5xx, 429, and network or timeout errors; back off exponentially with a ceiling so you stop hammering a struggling endpoint; cap the total at a fixed budget of attempts — on a 30-second doubling schedule, five attempts span about 8 minutes and eight span about an hour; then move the delivery to a dead-letter state for manual replay instead of retrying forever.

Everything else is tuning. The numbers below are a starting point, not a law — a payment provider and an internal analytics sink deserve different ceilings — but the shape is the same across almost every production webhook system, from Stripe's webhook delivery down to a single WordPress site.

/ Backoff

Why exponential backoff instead of fixed intervals?

Because the failure is usually the receiver being briefly overloaded or down. A fixed-interval retry hammers a struggling endpoint at a constant rate and can keep it down; exponential backoff gives the receiver geometrically more time to recover on each attempt while still retrying quickly for a one-second blip.

Add jitter — a small random offset on each delay — so a fleet of senders that all failed at the same moment does not re-fire in lockstep and create a thundering herd at every interval boundary. Even on a single site, jitter spreads retries off the exact minute mark and away from the rest of your cron load.

/ The schedule

What backoff schedule should you use?

Double the delay each attempt from a small base, cap it, and stop after a fixed count. A widely used shape is base 30 seconds, factor 2, ceiling 1 hour: retries after roughly 30s, 1m, 2m, 4m, 8m, 16m, 32m, and from there every retry pinned at the 1-hour cap. The formula is delay = min(cap, base * 2 ^ (attempt - 1)), plus a jitter term.

The Webhook Actions plugin uses the same shape with a shifted exponent and no jitter: the delay before retry N is base × 2^N, so on its defaults (30-second base, 1-hour cap, five attempts) a 5xx or 429 is retried after 60s, 120s, 240s and 480s, and the delivery is marked permanently_failed about 15 minutes after the first attempt. The cap only matters if you raise the limits. The attempt limit and the backoff strategy (exponential, linear or fixed, with its base and maximum delay) are per-webhook settings with a site-wide default; the fswa_max_attempts and fswa_backoff_delay filters override them in code^².

PHP — exponential backoff with jitter

function next_retry_delay( int $attempt ): int {
    $base = 30;     // seconds
    $cap  = 3600;   // 1 hour ceiling

    $delay = min( $cap, $base * ( 2 ** ( $attempt - 1 ) ) );

    // add up to 20% jitter so retries do not synchronize
    return $delay + random_int( 0, (int) ( $delay * 0.2 ) );
}

/ The schema

What database schema tracks retries?

Two tables. A deliveries row represents one logical webhook send and carries the state machine; an attempts row records each physical HTTP try so you keep the full request and response history. Splitting them keeps the hot path (find due deliveries) on a small, well-indexed table while the verbose request and response bodies live separately.

The columns that matter on deliveries: an event_id as the idempotency key, the endpoint and payload, a status enum (queued, sending, delivered, failed, dead), an attempt_count, and a next_attempt timestamp the runner queries against. Index on (status, next_attempt) so "what is due now" stays fast as the table grows.

SQL — deliveries table (the hot path)

CREATE TABLE wp_webhook_deliveries (
  id            BIGINT UNSIGNED AUTO_INCREMENT PRIMARY KEY,
  event_id      CHAR(36)     NOT NULL,            -- idempotency key
  endpoint_url  VARCHAR(512) NOT NULL,
  payload       LONGTEXT     NOT NULL,
  status        VARCHAR(20)  NOT NULL DEFAULT 'queued',
  attempt_count SMALLINT     NOT NULL DEFAULT 0,
  next_attempt  DATETIME     NULL,
  created_at    DATETIME     NOT NULL,
  UNIQUE KEY uq_event (event_id),
  KEY due (status, next_attempt)
);

/ What to retry

Which responses should trigger a retry?

Retry 5xx and 429; never retry 4xx (except 429) or 3xx. A 5xx means the receiver broke on a request that may be fine next time. A 429 means slow down — back off and try again. A 4xx like 400 or 422 means the payload itself is wrong, so retrying just fails again more slowly; mark it permanently failed and surface it. A 3xx redirect is a configuration problem, not a transient one. One caveat on WordPress: wp_remote_post() follows up to five redirects by default, so a 301 or 302 to a working URL is usually delivered rather than reported as a 3xx (a 303 also turns the POST into a GET). Pass 'redirection' => 0 if any redirect should count as a failure.

Treat network-level failures — DNS, connection refused, timeouts — like 5xx: retry them. They are the most common transient failure of all, and a request that timed out may well have one foot in the door, which is exactly why the next section matters.

/ When to stop

How do you stop retrying — dead-letter and idempotency?

Cap the attempts. When a delivery exhausts its budget, set its status to dead and surface it for manual replay rather than retrying forever; an endpoint that has failed every attempt across its whole retry window is down, not flaky. A dead-letter state turns an invisible silent failure into a queue someone can actually action.

Pair retries with an idempotency key — the event_id column above — sent as a header so the receiver can dedupe. Any retry policy is at-least-once delivery by definition: a request that timed out may have succeeded on the receiver before your timeout fired, so a retry delivers it twice. The key lets the receiver collapse those duplicates, the same pattern Stripe documents for its own webhooks. For a WordPress-specific build of this whole loop, see the retry and replay system walkthrough.

Retrying a 400 is just a slower way to fail. Backoff is for problems that time can fix. — Retry design, in one line
