Sending WooCommerce Order SMS Through Twilio Programmable Messaging

/ Hook choice

Which WooCommerce hook should fire the SMS?

The per-status hook, woocommerce_order_status_{to}, not the generic one — and the reason is a branch in WC_Order that costs people their first-order notifications.

Both hooks live in the same status-transition block in class-wc-order.php, but they are not siblings. The per-status action fires unconditionally; the generic one fires inside an if:

PHP — class-wc-order.php, status_transition()

// Always fires, including the very first status a new order gets.
do_action( 'woocommerce_order_status_' . $status_transition['to'],
    $this->get_id(), $this, $status_transition );

// ... status note added ...

if ( ! empty( $status_transition['from'] ) ) {
    do_action( 'woocommerce_order_status_' . $status_transition['from']
        . '_to_' . $status_transition['to'], $this->get_id(), $this );

    // Only reached when a PREVIOUS status existed.
    do_action( 'woocommerce_order_status_changed', $this->get_id(),
        $status_transition['from'], $status_transition['to'], $this );
}

An order created straight into processing by a gateway that captures immediately has an empty from. The per-status hook fires; woocommerce_order_status_changed does not. The bug this produces is nasty because it is partial: manual admin status changes work perfectly, so the feature tests fine and then misses a slice of real orders.

If you do bind the generic hook — for a state machine that genuinely needs the previous status — remember it passes four arguments and add_action() defaults to one:

PHP — the argument-count trap

// $from and $to are silently missing without the trailing 4.
add_action( 'woocommerce_order_status_changed', 'yp_order_changed', 10, 4 );

function yp_order_changed( $order_id, $from, $to, $order ) { /* ... */ }

/ Phone numbers

Why is the billing phone not safe to send?

Because WooCommerce never promised it was a phone number. This is the entire validator:

PHP — WC_Validation::is_phone()

public static function is_phone( $phone ) {
    if ( 0 < strlen( trim( preg_replace(
        '/[s#0-9_-+/().]/', '', $phone
    ) ) ) ) {
        return false;
    }

    return true;
}

Strip out digits, spaces and a handful of punctuation marks; if anything is left, reject. That is a character-class check, nothing more. It validates no country code, no length, no plausibility. Every one of these passes WooCommerce checkout and every one of them is rejected by Twilio with 21211 — Invalid 'To' Phone Number:

Worse, the field is not necessarily required. The checkout field definition sets 'required' => 'required' === CartCheckoutUtils::get_phone_field_visibility(), so on a store configured with phone optional you will be handed an empty string for a meaningful share of orders.

The fix is to normalise before you queue, and to treat a number you cannot normalise as a skipped notification rather than a failed order:

PHP — normalise, or decline to send

function yp_to_e164( $raw, $country ) {
    $digits = preg_replace( '/[^0-9+]/', '', (string) $raw );

    if ( '' === $digits ) {
        return null;
    }
    if ( 0 === strpos( $digits, '+' ) ) {
        return $digits;                       // already E.164
    }
    if ( 0 === strpos( $digits, '00' ) ) {
        return '+' . substr( $digits, 2 );        // 00 44 ... -> +44 ...
    }

    // A national number. Guessing the country from the billing address is
    // a heuristic, not a rule — use a real E.164 library in production.
    $prefixes = [ 'US' => '+1', 'GB' => '+44', 'PL' => '+48', 'DE' => '+49' ];
    if ( ! isset( $prefixes[ $country ] ) ) {
        return null;
    }

    return $prefixes[ $country ] . ltrim( $digits, '0' );
}

A phone field that validates punctuation is not a phone field. Treat the billing phone as untrusted free text and the rest of the integration gets simpler.

/ The call

How do you call the Twilio Messages API?

One POST, form-encoded, with HTTP Basic auth. No SDK is required — wp_remote_post() covers it, which keeps the dependency footprint at zero:

PHP — sending one message

function yp_send_sms( $to, $body ) {
    $sid   = defined( 'YP_TWILIO_SID' ) ? YP_TWILIO_SID : '';
    $token = defined( 'YP_TWILIO_TOKEN' ) ? YP_TWILIO_TOKEN : '';

    $response = wp_remote_post(
        "https://api.twilio.com/2010-04-01/Accounts/{$sid}/Messages.json",
        [
            'timeout' => 15,
            'headers' => [
                'Authorization' => 'Basic ' . base64_encode( "{$sid}:{$token}" ),
            ],
            'body'    => [
                'To'                  => $to,
                'MessagingServiceSid' => YP_TWILIO_SERVICE_SID,
                'Body'                => $body,
                'StatusCallback'      => rest_url( 'your-plugin/v1/sms-status' ),
                // Do not let a message sit in the queue for 10 hours.
                'ValidityPeriod'      => 600,
            ],
        ]
    );

    if ( is_wp_error( $response ) ) {
        return $response;                // transport failure — retryable
    }

    $code = wp_remote_retrieve_response_code( $response );
    $data = json_decode( wp_remote_retrieve_body( $response ), true );

    if ( 201 !== $code ) {
        // $data['code'] carries the Twilio error number, e.g. 21211.
        return new WP_Error( 'twilio', $data['message'] ?? '', $data );
    }

    return $data['sid'];        // status here is "queued", not "delivered"
}

Two parameters deserve more attention than they usually get. MessagingServiceSid and From are mutually exclusive, and using the service SID is what lets Twilio pick a sender from a pool — which is also where 10DLC registration is attached. ValidityPeriod defaults to 36,000 seconds, ten hours; for an order notification, a message that arrives ten hours late is worse than one that never arrives, so cap it.

/ Cost

What does an order SMS actually cost?

More than the per-message rate, because you are not billed per message — you are billed per segment. Twilio's limit is 160 GSM-7 characters per segment, or 70 UCS-2 characters once any character falls outside GSM-7, with a hard ceiling of 1,600 characters per message.

Take a plain notification at 150 characters. That is one segment. Now add a single emoji to make it friendlier:

• Plain, 150 chars, GSM-7 → 150 ÷ 160 = 1 segment.
• Same text plus one emoji → the whole message becomes UCS-2 → 151 ÷ 70 = 2.16 → 3 segments.
• At a US rate of $0.0079 per segment: $0.0079 versus 3 × $0.0079 = $0.0237.

Scale that to volume and the emoji is a line item. At 4,000 orders a month: 4,000 × $0.0079 = $31.60 plain, against 4,000 × $0.0237 = $94.80 with the emoji — $63.20 a month, $758.40 a year, for one character. Add the order number and a tracking URL and a "short" message routinely lands at 3 segments before anyone notices.

The practical control is to measure the body before you send it and to keep URLs out of the concatenation where you can. Note also that concatenated segments use 153 GSM-7 or 67 UCS-2 characters each, since the header that reassembles them consumes part of every segment — so the arithmetic above is the optimistic version.

/ Delivery

Should the send be inline or queued?

Queued, and the argument is not the usual hand-waving about performance. It is that woocommerce_order_status_changed fires inside the request that is processing the order — often the customer's checkout request, often a gateway's IPN callback.

A 15-second timeout on an HTTP call to Twilio is 15 seconds added to that request in the worst case. If it is the checkout, the buyer is looking at a spinner. If it is the gateway callback, the gateway may time out and retry, and now the order transitions again and you send a second SMS. The failure mode is not a slow page — it is a duplicate billed message caused by someone else's retry logic.

WordPress already ships the queue: Action Scheduler comes bundled with WooCommerce, so as_enqueue_async_action() is available on any store without adding a dependency. If you are new to it, how Action Scheduler works and building a job queue in WordPress cover the mechanics.

/ Callbacks

How do you track delivery with a status callback?

Twilio's 201 means accepted, not delivered — the status field in that response is queued. Of the full set of values (accepted, scheduled, queued, sending, sent, delivered, undelivered, failed, canceled, and the inbound ones), only delivered, undelivered, failed and canceled are terminal. Everything before that is in flight.

The StatusCallback URL receives those transitions — and it is a public endpoint receiving claims about your billing, so it must be verified. Twilio signs with X-Twilio-Signature, an HMAC-SHA1 keyed with your auth token, over the full webhook URL with the POST parameters sorted alphabetically and appended:

PHP — validating the status callback

function yp_valid_twilio_sig( $url, $params, $signature, $token ) {
    ksort( $params );

    $data = $url;
    foreach ( $params as $key => $value ) {
        $data .= $key . $value;
    }

    $expected = base64_encode( hash_hmac( 'sha1', $data, $token, true ) );

    return hash_equals( $expected, (string) $signature );
}

The URL has to be the exact one Twilio called, including the query string and its original percent-encoding. Twilio's own guidance is explicit: never pull query parameters out and pass them separately, and never decode or re-encode the URL — either breaks validation. Behind a reverse proxy this bites, because $_SERVER['HTTPS'] may be unset and you will rebuild an http:// URL that never matches.

/ Limits

What does Twilio not protect you from?

The expensive things.

1. Sending to an unregistered US number. Error 30034 — US A2P 10DLC: Message from an Unregistered Number blocks the message outright. Correct code, valid credentials, real phone number, and nothing arrives, because Brand and Campaign registration is a business process, not a code path. It also fires if the number is simply missing from the Sender Pool of the registered Messaging Service.
2. Consent. Twilio will happily deliver a marketing message to someone who only ever bought a product. Transactional order updates and marketing are different legal categories, and the checkbox that separates them is yours to build and store.
3. Spend. There is no per-order or per-customer cap by default. A retry loop that re-fires a status transition sends — and bills — every time. The order ID plus target status makes a natural idempotency key; use it.
4. Your credentials at rest. The auth token signs the callbacks as well as authenticating the sends, so it is both a spending key and a forgery key. It belongs in wp-config.php or the environment, never in the options table and never in a file under the webroot.
